10×30w Zoom Beam Wash Bar Moving Head Light

Model : MHBAR1030

TECHNICAL SPECIFICATIONS:

TECHNICAL PARAMETERS

POWER SUPPLY

Voltage:110-240V 50/60 Hz

Power consumption: 450W

LIGHT SOURCE

10x30w RGBW 4in1 Leds

Average life: 50,000 h

OPTICS

32bit 0-100% linear electronic dimmer

1-30Hz adjustable speed stop/strobe effect

EFFECTS SECTION

Moving tilt Beam+Beam pixel running

CONTROL AND PROGRAMMING

Channel models: 14CH/50CH

Display: LED display with 4 operating buttons

DMX signal connection: 3pin or 5pin in&out

DMX512, Auto run, Master/Slave, Sound active, with RDM

Power connection: Powercon in&out

Cooling:High efficiency die-cast aluminium, forced ventilation

MOVING BODY

Movement by means of 3 phase stepper motors, controlled by microprocessor.

Tilt movement: : 270°

Tilt Resolution: 16 bit

IP rate: IP20

WEIGHT&DIMENSION

N.G:9.6Kgs

Size:110*10*25cm
