TECHNICAL SPECIFICATIONS:

LIGHT SOURCE
Lamp: MSD 10R 280W bulb

CT: 7500 K
Lifespan: 2,000H

OPTICS
Zoom range: 3°–28°
High precision glass optic system
Improved optics and flat beam field

COLORS
1 Color wheel: 13 color+open
Half-color effect, linear color change, bidirectional rotating rainbow effect

GOBOS
1 Static gobo：13 gobos+open, shakable and bi-directionally rotatable at variable speeds
1 Rotating gobo： 9 gobos +open, shakable and bi-directionally rotatable at variable speeds

MOVEMENT
Pan movement: 540°(16 bit )
Tilt movement: 270°(16 bit )
Advanced moving system: auto repositioning, fast, quiet and smooth

FEATURES
Prism: 8-facet circular+ 6-facet linear prisms , bi-directionally rotatable at variable speeds
Frost: 1 frost filter, soft and natural wash effect
Strobe: mechanical shutter , variable from 1-20Hz or random
Dimming: mechanical dimmer 0-100% linearly adjustable
Focus: motorized linear focus
Zoom range:
Beam mode 3°- 20°
Spot mode 8°- 25°
Wash mode 10°- 28°

DISPLAY
2.8 inch full color touch LCD screen, show customer logo
15 second standby auto lock

SOFTWARE
Control mode: DMX512, master-slave, auto-run, sound activate
Channel: 16/24 CH
Run time of lamp and fixture record

OTHER SPEC
Fixture and lamp usage time display
Highly positioning precision
Adjustable fan speed
Built-in analyzer for easy fault finding, error messages
Input signal isolating protection
Auto thermal protection circuit
Housing: high temperature UV resistant ABS

POWER
Voltage: AC100-240V, 50/60Hz
Power Consumption: 450w@220V

DIMENSIONS AND WEIGHT
Fixture dimension: 40*33*58cm
Packing dimension:72x38x49cm(Carton)
86x40x80cm(2 in 1 flightcase)

Net Weight: 18kg
Gross Weight: 20kg(Carton)
58kg(2 in 1 flightcase)
