Moving Bar 12x40w RGBW Zoom

Category LED BAR WALL WASHER

Moving Bar 12x40w RGBW Zoom

TECHNICAL SPECIFICATIONS:

-Led type : 12*40W 4 in 1 Tianxin led, 144*0.3W 5050 RGB LED

-Lifespan : 50000H , low consumption , energy saving protection

-8bit and 16bit fine tuning

-Smooth and precise positioning

-Tilt: 196°

-Memorable scan positioning , reset without unexpected rotation .

-Tilt error correction function

-Channels: CH26, CH38, CH62, CH74, CH194.

-Control mode: DMX512 , sound , master-slave , RDM

-0-20Hz strobe effect

-Auxiliary light effect , can be chasing , running effect

-LCD display and 4 function button operation

-Fan cooling (speed adjustable with temperature changing)

-LED temperature detection protect led’s lifespan

-Multiple units can be jointed seamlessly

-Power connection: PowerCON power input and output

-DMX socket : 3 pin socket input and output

-Voltage: AC100~240V 50/60HZ

-Power: 580W

-Housing material : aluminum+metal

-IP rating : IP20

-Product size : 100x29x13 cm

-Net weight : 14.5 kg

Additional information

Exploring The Product

Description

Moving Bar 12x40w RGBW has a unique design, allowing seamless connection between fixtures. The lights are evenly spaced and produce parallel beams. It features 12x40W RGBW LEDs with a beam angle of 4 to 30 degrees, and each light source can be controlled individually. The fixture also includes 144x0.3W 5050 RGB LEDs, capable of creating an LED strip effect with chase and running light effects, and can be controlled in segments. In addition to DMX control, it offers powerful RDM functionality. The combination of dynamic beams and auxiliary LED strip lighting can create an extraordinarily brilliant effect.
