Optics

. LED type：1x120W RGBW, 24×0.2W RGB LED

. Beam angle: 24°

Movement

. Pan/tilt operation:：

-16bit fine-tuning

-Smooth and precise positioning

-Pan：540°，Tilt:205°

-Pan and Tilt speed adjustable

-The scanning position can be memorized and will automatically reset when there is no expected operation.

-Pan and Tilt with error correction function

 Colour

. RGBW ,  RGB background colour

Specifications

. DMX Channel：22CH

. 2 control model :DMX512、master-slave

. Dimming: 0-100% 16bit dimming

. Background light effect: capable of chasing and running horses

. 0-20Hz flicker, pulse flicker, random flicker effect

Display

. LED display screen operating

Other functions

. Settings and Addressing: RDM

.  Fan cooling (fan speed changes with temperature)

. LED temperature detection system to protect the lifespan of lamp beads

Power/signal link

. Power connection: PowerCON power cord input and output

. DMX: 3 Pin XLR inputs and outputs

Power

. AC100-240V 50/60HZ

. Power consumption：150W

Protection level

. Housing materials：ABS plastic fireproof material

. IP class：IP20

Work environment

. Indoor working temperature：-20°C～+40°C

Size/Weight

.Product Dimensions : 204x147x254 mm

. Packaging size: 255*200*360mm

. Net weight：3.6KG

. Gross weight：4.7KG
